Category: Butterfly Valve
U Shaped Butterfly Valve Gear Operated
Model:D341X
Working pressure :16 Bar
Working temperature:0~110°C
Nominal size:DN 50-1200
End connection:Double flange
Connection standards:AS, ASME,BS, DIN,EN, ISO, JIS
Body material:Ductile iron, GGG40/50, EN-GJS-400-15, SG iron material
Body coating:Epoxy
Seat material:EPDM, NBR, PTFE
Disc materials:Ductile iron,SS304, SS316, Aluminum-bronze
Disc coating:EPDM, Epoxy, Halar, Nylon
Actuator:Lever handle, Worm gearbox, Penumatic, Electrical
|
SIZE |
DN |
L |
D2 |
D |
D1 |
N-ΦG |
ISO5211 |
|||
|
PN10 |
PN16 |
150LB |
JIS10K |
|||||||
|
2" |
50 |
43 |
125 |
125 |
120.6 |
120 |
65 |
50 |
4-Φ8 |
F05 |
|
2-1/2" |
65 |
46 |
145 |
145 |
139.7 |
140 |
65 |
50 |
4-Φ8 |
F05 |
|
3" |
85 |
46 |
160 |
160 |
152.4 |
150 |
65 |
50 |
4-Φ10 |
F05 |
|
4" |
100 |
52 |
180 |
180 |
190.5 |
175 |
90 |
70 |
4-Φ10 |
F07 |
|
5" |
125 |
56 |
210 |
210 |
215.9 |
210 |
90 |
70 |
4-Φ10 |
F07 |
|
6" |
150 |
56 |
240 |
240 |
241.3 |
240 |
90 |
70 |
4-Φ10 |
F07 |
|
8" |
200 |
60 |
295 |
295 |
298.4 |
290 |
125 |
102 |
4-Φ12 |
F10 |
|
10" |
250 |
68 |
350 |
355 |
361.9 |
355 |
125 |
102 |
4-Φ12 |
F10 |
|
12" |
300 |
78 |
400 |
410 |
431.8 |
400 |
125 |
102 |
4-Φ12 |
F10 |
|
14" |
350 |
78 |
460 |
470 |
476.2 |
445 |
125 |
102 |
4-Φ12 |
F14 |
|
16" |
400 |
86 |
515 |
525 |
539.7 |
510 |
175 |
140 |
4-Φ18 |
F14 |
|
18" |
450 |
105 |
565 |
585 |
577.8 |
565 |
175 |
140 |
4-Φ18 |
F14 |
|
20" |
500 |
130 |
620 |
650 |
635 |
620 |
175 |
140 |
4-Φ18 |
F14 |
|
24" |
600 |
152 |
725 |
770 |
749.3 |
730 |
210 |
165 |
4-Φ22 |
F16 |
