Category: Butterfly Valve
Vulcanized Rubber Seat Butterfly Valve Double Flange Type
Model:D41X
Working pressure :16 Bar
Working temperature: 0~110°C
Nominal size:DN 50-200
End connection:Wafer
Connection standards:AS, ASME,BS, DIN,EN, ISO, JIS
Body material:Ductile iron, GGG40/50, EN-GJS-400-15, SG iron material
Body coating:Epoxy
Seat material:EPDM, NBR, Hypalon, PTFE
Disc materials:Ductile iron,SS304, SS316, Aluminum-bronze
Disc coating:EPDM, Epoxy, Halar, Nylon
Actuator:Lever handle, Worm gearbox, Penumatic, Electrical
|
SIZE |
DN |
L |
D2 |
D4 |
D5 |
N-Φd |
ISO5211 |
|||
|
PN10 |
PN16 |
150LB |
JIS10K |
|||||||
|
2" |
50 |
108 |
125 |
125 |
120.6 |
120 |
65 |
50 |
4-Φ8 |
F05 |
|
2-1/2" |
65 |
112 |
145 |
145 |
139.7 |
140 |
65 |
50 |
4-Φ8 |
F05 |
|
3" |
85 |
114 |
160 |
160 |
152.4 |
150 |
65 |
50 |
4-Φ10 |
F05 |
|
4" |
100 |
127 |
180 |
180 |
190.5 |
175 |
90 |
70 |
4-Φ10 |
F07 |
|
5" |
125 |
140 |
210 |
210 |
215.9 |
210 |
90 |
70 |
4-Φ10 |
F07 |
|
6" |
150 |
140 |
240 |
240 |
241.3 |
240 |
90 |
70 |
4-Φ10 |
F07 |
|
8" |
200 |
152 |
295 |
295 |
298.4 |
290 |
125 |
102 |
4-Φ12 |
F10 |
